Peb lub tuam txhab tau tsim nyob rau hauv 2007 thiab nyob rau hauv Yantai, Shandong xeev - qhov chaw yug ntawm Tuam Tshoj lub polyurethane khoom kev lag luam. Qhov tseem ceeb, Wanhua, ib qho ntawm Tuam Tshoj cov khoom siv raw khoom loj tshaj plaws, tseem nyob ntawm no. Txij li thaum peb nrhiav tau, peb tau mob siab rau R & D, ntau lawm, thiab muag khoom ntawm polyurethane khoom. Peb cov khoom muaj xws li polyurethane log, polyurethane cua hoses, polyurethane nplooj ntawv, polyurethane cov ntxaij vab tshaus, polyurethane forklift lub tes tsho, polyurethane pipeline npua, thiab lwm yam khoom polyurethane. Peb tau nruab nrog ntau cov kab ntau lawm thiab cov cuab yeej ntsuas kom ntseeg tau tias txhua theem ntawm kev tsim khoom-xws li peb pallet polyurethane load log- ua tau raws li cov kev cai nruj. Koj zoo siab tos txais tuaj xyuas peb lub Hoobkas txhua lub sijhawm.

Load suav

Load xam rau siab -kev ua tau zoo pallet polyurethane load log tsis yog ib qho yooj yim kho mis; nws yuav tsum xav txog ntau yam. Ib txoj kev tso cai yog raws li nram no:

T = (E + Z) / n × S

Qhov twg:

T=yuav tsum muaj peev xwm thauj khoom ib lub log (qhov no yog lub hauv paus rau koj xaiv)

E=qhov hnyav ntawm cov khoom thauj (piv txwv li, lub laub lossis AGV)

Z=qhov hnyav tshaj qhov hnyav ntawm cov khoom siv

n=tus naj npawb ntawm cov log siv (Ceeb Toom: Thaum siv 4 lub log, cov khoom xa tawm feem ntau tsis sib npaug vim cov plag tsev tsis sib xws; yog li ntawd, n feem ntau siv li 3, piv txwv tias tsuas yog 3 lub log nqa tag nrho cov load.)

S=yam kev nyab xeeb – ib qho kev hloov pauv tseem ceeb uas nyob ntawm seb qhov kev ua haujlwm tiag tiag txawv li cas los ntawm "cov xwm txheej zoo" (nruab pem teb, qis ceev, chav tsev kub)

Safety factor (S) siv qhov tseem ceeb:

Kev Ua Haujlwm Kev Nyab Xeeb Kev Nyab Xeeb (S)

Sab hauv phau ntawv thawb (obstacles <5% ntawm lub log txoj kab uas hla) 1.0 - 1.5

Sab nraum zoov phau ntawv thawb (obstacles> 5% ntawm lub log txoj kab uas hla) 1.5 - 2.2

Sab hauv tsev siv hluav taws xob / tsis siv neeg (cov teeb meem <5% ntawm lub log txoj kab uas hla) 1.4 - 2.0

Sab nraum zoov powered / automated 2.0 - 3.0

Piv txwv:

Ib qho AGV nrog qhov hnyav ntawm 200 kg thiab qhov siab tshaj plaws ntawm 800 kg ua haujlwm sab hauv tsev hauv pem teb nrog cov teeb meem me me (siv S=1.8). Nws siv 4 lub log (n=3).

Qhov yuav tsum tau muaj peev xwm load ib lub log yog:

T=(200 + 800) / 3 × 1.8=600 kg

Tshaj li ntawm cov qauv, lub pallet polyurethane load log lub cev qhov ntev (txoj kab uas hla loj=siab dua load peev) thiab hardness ntawm polyurethane khoom (feem ntau ntawm 75 thiab 96 Shore A) kuj ncaj qha txiav txim siab qhov kawg load ntsuam xyuas.
